AQUASITION
Yacht for Sale

This 142' 2010 Trinity TDMY AQUASITION, was built as Hull # 48 for a knowledgeable yachting connoisseur. The attention to detail and subsequent maintenance and recent refit improvements are spectacular. This is a remarkable yacht offering elegance, yet comfortable, spacious accommodations and desirable layout for both family cruising and charter.

Her layout features five staterooms for up to ten guests plus eight in crew quarters. Her spectacular interior features cherry wood joinery with maple burl inserts throughout. Her interior decor has been redone in 2023 with new furnishings, decorative lighting and LED recessed lights throughout, updated audio/video system, new carpeting, window treatments, new fabrics and soft goods throughout. In addition, the vessel received new 29" touchscreen monitors, exterior teak furnishings, new upholstered cushions throughout and new Tucci sunshades installed.

In addition, over $130K being spent on her complete new custom built air conditioning water chiller and heater system by CuGe Marine with (3) new custom air chillers at 438,225 BTU's, (11/24).

• Interior refit throughout by Yacht Next in 2023
• (2) Ferrel Mittman upholstered sectional sofas
• (2) Custom cherry & quartzite cocktail tables

• New Linen & Viscose carpeting

• Cherry & maple entertainment center w/Samsung LED 55" TV

• Built-in cherry w/maple burl buffets w/marble tops, storage, port & stbd

• Full glass floor to ceiling, sliding electric doors aft w/drapes, aft

• (4) Custom decorative wall sconces
• (2) Decorative mirrors, port & stbd aft

• Marble flooring at aft entryway
• Built-in cherry wood w/maple burl cabinetry w/marble tops, port & stbd, w/custom storage
• Built-in cherry w/maple burl buffet/cabinetry w/marble top, centerline, dividing salon and formal dining area w/lofted storage

• Custom Majilite finesse padded panel headliner throughout

  Dining Area:


• Custom teak dining table w/intricate marquetry inlays
• (8) New custom upholstered dining chairs
• Built-in cherry w/mahogany inserts side buffets, port & starboard, w/custom lofted storage

• Custom artwork w/lighting on forward bulkhead
• (2) Custom decorative wall sconces, port & starboard

• New LED lighting throughout


  Main Foyer/Entryway:


• Marble flooring
• Side entry doors, port & starboard
• Day head w/marble vanity, decorative sink & gold plated fixtures

• Stairwells w/custom iron rails, up to skylounge & down to guest accommodations

• Double Delfield refrigerator/freezers
• Wolf induction 6-burner cooktop
• Wolf induction 2-burner cooktop
• (2) KitchenAid convections ovens
• Industrial Panasonic microwave
• Undercounter mini freezer

• (2) Miele dishwashers

• Vulcan Salamander Industrial broiler
• Sub-Zero wine cooler

• Scotsman icemaker
• (2) Insinkerator garbage disposals

• Center island w/granite top & stainless steel sink
• Granite tops throughout
• Walk-in pantry
• Insignia 30" TV w/Direct TV & CCTV

• All new soft goods, 2023
• King berth w/tufted linen headboard & bulkhead by George Spensor
• Custom bedding & embroidered fine linen by Hamburg House
• (2) Built-in cherry w/maple burle nightstands w/marble top & lamps & mirrored wall panels

• Built-in cherry w/maple burle dressers, port & stbd
• Built-in cherry w/maple burl vanity w/ upholstered bench seat, port
• Cherry w/maple burl entertainment center aft w/ 55" HD TV
• New Fabrica carpeting
• New upholstered wallcoverings by George Spensor England

• New window treatments by Nancy Corzine w/swags

• Custom overhead soffit, LED & indirect rope lighting

• Walk-in, aromatic cedar lined closets w/double doors

• Radius double door entryway to master w/study area
• Built-in cherry w/maple burl desk w/drawers, marble borders & chair
• (2) Custom upholstered Nancy Corzine chairs & cherry table

  His & Her Master Bath:


• Cherry w/maple burl vanities w/ marble surfaces

• (2) Custom decorative sinks w/gold plated fixtures
• Custom decorative gold framed mirrors
• Marble shower w/seamless glass enclosure, built-in seat & light
• Marble Jacuzzi tub w/built-in shelving & gold plated fixtures
• (2) Water closets, port & stbd


• King berths w/custom bedding & custom embroidered fine linens
• New custom window treatment w/shades & swags

• (2) Built-in cherry/maple burl nightstands w/marble surface & lamps
• (2) Mirrored wall panels, port & starboard
• Built-in cherry w/maple burl dresser drawers

• Built-in vanity w/mirror, bench seat & cabinets above
• Entertainment center aft w/Samsung 43" QLED Frame series TV
• Custom backlit acrylic artwork w/ gold plated frame

• Aromatic cedar-lined closets

  Guest Baths:


• Cherry vanities w/marble surfaces
• Custom decorative vanity w/sink & gold plated fixtures
• Seamless glass enclosed shower w/tub & gold plated fixtures
• Custom wallcoverings

• All new soft goods in 2023
• Twin berths w/custom bedding & embroidered fine linens

• New Cortina tufted leather padding around berths
• Built-in cherry w/maple burl nightstand w/marble top & reading lamp
• (2) Decorative starburst mirrors
• Custom linen wallcovering

• Built-in cherry w/maple burl vanity w/marble surface & bench seat
• Samsung 43" QLED Frame series TV, aft
• Custom backlit Acrylic artwork w/ gold plated frame
• Cedar-lined hanging closet
• Private bath w/marble top vanity, mirror, decorative sink, gold plated fixtures, seamless glass enclosed shower & custom fixtures

  Lower Companionway / Foyer:


• Miele full size washer/dryer

• Sub-Zero undercounter refrigerator

• Sub-Zero undercounter freezer
• Art niche w/ marble surface, custom paint w/lighting & cabinets below
• New LED recessed & indirect rope lighting

• Decorative framed full length mirror on forward bulkhead

• Captain's cabin w/queen berth & upholstered headboard, Samsung 55" TV, Pioneer DVD, hanging locker, B&G wind/speed/depth display, private bath w/shower

• (3) Crew cabins w/over & under berths for (6) crew, ensuite heads

• Engineer cabin located aft w/double berth for (2)
• Office to port
• Security camera controls

• (2) Miele washers & dryers
• Oversized upholstered crew dinette w/corian table
• Undercounter Sub-Zero refrigerator
• Whirlpool mircrowave
• Samsung 40" TV
• Neovo 20" camera/monitoring system w/ 5 cameras
• Standard Horizon VHF
• Amtico flooring


• New custom upholstered sofa & (2) chairs

• New cherry/maple round game table & (4) upholstered chairs
• New grass cloth wallcoverings

• New Ironies Penshell occasional table

• New custom bar front in tufted leather by Jerry Pair
• Custom cherry/mahogany bar w/onyx surface, custom sink, Sherrill Wagner fixture & marble flooring

• (3) New upholstered hi-back bar stools
• Beveled mirrored bulkhead behind bar
• Sub-Zero wine cooler, Marvel refrigerator & Hoshizak icemaker

• Built-in Sony 55" LED TV

• New wall mirrors installed
• New indirect lighting
• Custom Fabrica carpeting
• New custom window treatments

• Wall to wall, floor to ceiling, double glass electric sliding doors w/privacy drapes to upper aft deck

  Day Head:


• Starboard side of skylounge w/marble vanity, mirror, decorative sink, gold plated fixtures


• Furuno 2137 Band 120-mile Radar

• Furuno XBand 2127 120-mile Radar
• (2) Furuno AIS GP90 MX420 GPS
• Furuno NX 700P Navtex
• C-Plath Navipilot 4000 autopilot
• C-Plath Navigat X MKII STD 22 Gyro
• (5) B-Tronics 29" touchscreen monitor displays (11/24)
• C-Plath magnetic compass

• Furuno PB100 echo sounder
• Transas chart plotter
• B&G wind / log
• (2) New Starlink flat panel antennas (2023)
• Seatel 4006 VSat Sat Com Sailor Fleet One voice
• Furuno 8800S VHF w/weather station sensor
• Furuno FS1570 SSB
• Furuno NX 700P receiver
• Ericson GMS cellular w/power max DA4100
• (2) Crown adjustable helm chairs w/new leather upholstery ('24)
• New Leather upholstered settee ('24) w/ corian table
• Custom recessed overhead w/ world map & lighting


• New Quartizte surfaces & countertops
• All exterior cushions reupholstered
• New Samsung waterproof LED TV
• High gloss teak round dining table
• (10) Summit Teak dining chairs
• (4) Summit Teak deck chairs w/cushions & ottomans

• Summit Teak sectional settee w/cushions, aft
• Oval high gloss teak cocktail table w/stainless steel pedestal
• (10) Summit Teak dining chairs
• (2) Teak round end tables
• Overhead LED recessed lighting
• Stereo speakers

• Teak decks
• Spiral stairway to upper sun deck
• Stairwell down to main aft deck
• Double sliding glass doors to skylounge

• New teak settee w/cushions, aft

• (2) New teak swivel chairs w/cushions
• (2) New teak chairs w/cushions & ottomons
• Teak oval cocktail table & (4) teak round end tables
• New 8' Tucci umbrellas
• New outdoor area rug, aft
• (3) New chaise sunlounges w/cushions
• Jacuzzi 8-person w/ teak steps & cover, forward centerline

• New 6' sunpads, built-in each side of Jacuzzi, port & stbd

• Bar w/new Quartzite stone top, icemaker, refrigerator, sink & storage cabinets

• (6) Adjustable bar stools w/new upholstered cushions & stainless pedestal & footrest

• New Seura all weather TV
• Built-in settee w/cushions & teak dining table

• Stainless steel hoop rails, around aft perimeter
• Stainless steel guard rails w/safety glass, around perimeter forward
• Day head w/new Quartzite stone vanity, sink & mirror
• Teak decking
• (2) 2022 Yamaha VX waverunners
• Spiral stairway down to skylounge deck


• Custom high gloss teak table w/ inlay
• (6) Summit Teak chairs w/cushions
• Built-in bench seating w/new cushions

• All new Quartzite stone surfaces
• New upholstered cushions
• Stairway up to sundeck
• Double glass sliding doors to main salon

• Teak decking
• Dual stairways to swim platform w/teak steps & stainless handrail
• Teak swim platform w/ (4) stainless steel hoop rails

• New carbon fiber davit on swim platform for waverunners
• Watertight access door to lazarette and engine room


• Nautical Structure EZ 3500lb crane, telescopes to 21'
• (2) Muir VC4000 hydraulic aft warping capstans
• (2) 450lb anchors w/5/8" galvanized chains, 450' per side

• Marquipt 20' hydraulic passerelle
• (2) Marquipt 9-step side boarding ladders
• (2) ACR RCL 1000 searchlights
• Carbon fiber davit 500kg
• (4) Viking 20-person life rafts

• Teak decks

• Teak swim platform w/new carbon fiber davit or waverunners

• All exterior cushions
• Access to Portuguese deck w/ new upholstered settee

• Twin Kilopack 99KW Generators, 1800 RPM's
  Port Gen rebuilt 5/20 - Hrs: 8694 (Total Hrs: 9784)
  Stbd Gen rebuilt 8/23 - Hrs: 5902 (Total Hrs: 8082)
• Racor fuel filters for gens
• 3-Phase 208v-phase shore power
• Atlas shore power system

• AMG Odyssey PC 1800 marine batteries
• (10) 12v Odyssey main batteries
• (4) Mastervolt 24/50 battery chargers
• (2) Mastervolt 24/100 battery chargers

• Panasonic Pelco CCTV security system


• Twin Caterpillar C32A, 1800 HP @ 2300 RPM's
  Complete overhaul on both engines, 5/22
  Port: 1245 Hrs SMOH / Stbd: 1239 Hrs SMOH
• Marine Air chilled water system, (3) compressors, 36-tons
• (2) FCI Watermakers

• (2) Reintjes WAF542 gear boxes
• Quantum QT120 120HP hydraulic bow thruster
• Quantum QC-1500 zero-speed stabilizers

• Triple Racor 1000 fuel filters for main engines
• Cat Spin on secondary filters

• Alfa Laval fuel separator
• Boss oil/water separator
• EMI electric steering system

• (2) Nibral 5-bladed props
• Aquatech 22 prop shafts
• Headhunter / Edson sewage treatment system
• Fixed fire suppression, (3) CO2 282lb
• Kidde dry chemical extinguishers throughout
• Auxillary fire pump system, 208v primary
• Walker Air Seps
• Twin water cooled turbo chargers
• Raw water cooled after coolers
• Delta T blower
• Freshwater engine cooling system
• Raw water sea strainers

• Dripless seal stuff box
• (3) Sump bilge pumps 208v electric/auto

• (2) Air compressors

• In process 11/24 - Custom built chiller, control panel & frame at 128.4KW, (438,225 BTU) comprising of (3) refrigeration circuits, with one compressor, condenser and evaporator per circuit. Each compressor will modulate on capacity via variable frequency drives from 35-60 Hz. The evaporator configuration will comprise of (3) single circuit brazed plate heat exchangers. The condenser configuration will comprise of (3) shell and pipe condensers and new immersion heater controls.

• Consisting of R410 Refrigerant; PVE 32 lubricant water-cooled package chiller. Model CCBS-128-LC; 208 volts/3/60 Hz; Air conditioning chiller/immersion heat

  (3) Compressors:


• Comprising of (3) Bitzer, scroll compressors
• Each compressor is rated @ 42.8 KW (146,075 BTU/h; 12.17 TR) @ 60 Hz
• Power input: 10.11 KW each 30.33 KW total @ 100%
• THR: 52.9 KW (137,201 BTU/h; 15.04 BTU/h) each circuit 100%

  (3) Frequency Drives:


• Variable frequency drives, Altiva 320 manufactured by Schneider Electric, rated @ 66 amps to start each compressor individually. This reduces the inrush start current and allow compressor start up on limited shore power. The drives also control the compressor capacity

  (3) Condensers:


• Shell and tube construction, 90/10 Cupro nickel tubes, 90/10 Cupro nickel tube sheets, bronze headers & carbon steel shell manufactured by Onda SPA
• Water in: 86 F each
• Water out: 95 F each
• Cond temp: 104 F each
• Flow Rate:
• Capacity: 56 KW (177,474 BTU/h; 14.78 TR) each

  (3) Evaporators:

• Electronic expansion valves and hot gas by-pass capacity controls
• Brazed plate, single circuit evaporator by Onda SPA, piped in parallel
• Water in: 53.6 F
• Water out: 44.6 F
• Evap temp: 35.6 F
• Flow rate: 31.80 GPM ea
• Capacity: 153,583. BTU/h ea

  Control Panel:

  The panel is built for the chiller application. The package controls each cooling stage and all safety functions as follows:

• Capacity control
• Chilled water in and out temperature
• Sea water in and out temperature
• Suction, discharge pressure for each circuit
• Safety lockout for low and high pressure, motor overload, freeze, flow failure, failure, VFD failure
• Select lead lag operation automatically in balance operating hours of each compressor
• Preprogrammed with schematic drawing of electrical circuit
• Inter connection cables, IEEE class
• D Rated circuit breakers for compressor, pumps & control circuit protection
• Contactors & thermal overload to serve sea water & chilled water pumps
• Variable frequency drive to control sea water pump speed to maintain 105.7F condensing temperature for optimum performance & increased life expectancy of pump internal parts and condenser tubes
• DIN rail mounted terminals for external wiring connections
• Panel cooling fan with filter housing
• Door fascia with markings for system operation

  Chiller Frame:

• The chiller frame constructed from modular aluminum 6105 with a T5 temper anodized. All major components installed onto frame as required

  Pumps:

• (2) Chilled water pumps, run and standby, rated at 98 GPM @ 50' head @ 60 Hz
• (2) Sea water pumps, run and standby, rated to 110GPM @ 16' @ 60 Hz

  Immersion Heater:

• 12KW of heating capacity, controlled by SCR variable heat output control, consisting of high amp, high temperature & high pressure safety device

  Chiller & Frame:

• Chiller custom manufactured. Brazing carried out using oxygen free nitrogen purging. Each circuit is pressure and leak tested
• Chiller control panel custom built for application. Panel is bench tested, all
  compressors, condensers, filter drier casings & control panel finished in Awlgrip coating

  Chilled & Sea Water Piping:

• Copper manifold & piping to and from chillers & pumps
• Sea water connected to existing services

• Complete ABS 10-Year Survey / Reclassification (2020)
• Complete bottom job (8/22)
• New custom interior by Yacht Next & Grand Interiors Int'l (2023)
• (5) New B-Tronics touchscreen monitor displays (11/24)
• New salon & skylounge furnishings
• New soft goods throughout to include fabrics, bedding, lighting & TV's in all staterooms

• All next exterior cushions & sunpads

• New davit for waverunners
• New KitchenAid convection ovens & freezer

• New Samsung LED HD TV's throughout & distribution system upgraded to 4K
• New stabilized HD Intellian S80 TVRO dome antenna
• A/V systems has been completely updated w/highest quality components
• Communications upgraded allowing bonding of (2) 4G cell receivers for cost effective internet
• New (2) Yamaha 1010CC Waverunners

• New LED lighting throughout vessel
• All decks sanded (9/24)
• New Quartz stone top for flybridge bar ('19)

AQUASITION represents one of the finest Trinity's built to ABS, Maltese Cross 100-A1 and AMS classifications. The attention was given to every detail, subsequent maintenance and recent refit improvements make this 142' Trinity truly in turn-key condition.

Her layout features (5) staterooms for up to (10) guests with on-deck Master, (3) King guests and twin stateroom, plus (5) in crew quarters. Her interior decor has been redone in 2023 with new furnishing, fabrics and soft goods, new LED recessed lighting, updated audio/video equipment to include new LED TV's throughout. The vessel also received new 29" touchscreen monitors, exterior teak furnishings, new cushions throughout and Tucci sunshades.

Powered by reliable Caterpillar C-32's, she cruises comfortable at 14 knots with an 18 knot top end speed. Her 15,000 gallon fuel capacity provides for extended range of 3000 miles. With a full paint job in 2017, an extensive interior refit and custom built complete air conditioning system in process (11/24), along with ABS 10-year recertification in 2020, AQUASITION is highly maintained and in flawless condition!

• All owner's & crew personal items
• The 'Aquasition' name
