FRIENDSHIP
Yacht for Sale

General
Length Overall: 173.24 feet (52.80 meters)
Beam: 31.00 feet ( 9.45 meters)
Draft (loaded): 12.47 feet ( 3.80 meters)
Tonnage: 643 gross; 192 net tons

Capacities
Fuel Capacity: 29,291 US Gallons (110,800 liters)
Water Capacity: 6,900 US Gallons ( 26,200 liters)
Watermakers: 6,340 US Gallons ( 24,000 liters)
Lube Oil: 240 US Gallons ( 910 liters)
Waste Oil: 240 US Gallons ( 910 liters)
Grey Water: 2,800 US Gallons ( 10,600 liters)
Black Water: 391 US Gallons ( 1,480 liters)

Speed / Consumption per hours / Range / RPM
Maximum: 16.0 knots 730 liters (193 US Gal) 2,000
Cruising: 14.5 knots 450 liters (119 US Gal) 1,750
Economical: 11.5 knots 335 liters ( 66 US Gal) 5,100 nm 1,450
Average consumption including Genset: 335 liters (88.5 US gallons) per hour

Main Engines
Engine Type:

• (2) MTU 12V396TE74 diesels @ 1,750 Hp each
• W6 Major Overhaul on Main Engines completed:
  • Starboard: May, 2018 @ 15,297 hrs / Current hours: 19,004 – Sept., 2024
  • Port: August, 2016 @ 13,826 hrs. / 18,940 – Sept., 2024

Gearboxes for Main Engines:

• ZF BW-461

Drive:

• Twin screw propellers

Generators & Electricity
Output:

• 400V/3 Phase/50 Hz / 230V/Single Phase/50 Hz

Generators:

• (2) 142 kW MTU/Mercedes 8V1831
• (1) Lister/Petter TS33BV3 emergency generator
• W6 Major Overhaul on Port & Starboard:
  • Completed January, 2023 – Approx. 6,600
  hrs SMOH / Current Hours: Port – 61,234 / Starboard – 61,299 – Sept., 2024

Generator Fuel Consumption:

• 335 liters (88.5 US gallons) per hour

Shore Power:

• 400V/3 Phase/50 Hz

Batteries:

• 5 Banks 24VDC

Air Conditioning
Type: • Heinen & Hopman/Marine Air 75 ton
 
Other Machinery
Watermakers:

• (2) HEM 30/3200 1000 liters (264 US gallons) per hour

Stabilizers:

• Running - Vosper
• At anchor - (2) Quantum Zero Speed

Bow Thruster:

• Rexroth

Steering System:

• Cramm/Rexroth

Fuel Separator & Filtration:

• Racor filters and Alfa Laval MMPX 303 SGP-11 separator

Sewage System:

• Haman Norway Mini

Fresh Water System:

• (3) Hydrophore pumps and accumulator

Rudder Angle Indicator:

• Anschutz

Bilge Water Filtration:

• Johnson CH 40-200

Oil/Water Separator:

• Hodges 9422

Boilers:

• (2) ACV E-Tech 22

WCs:

• Evac

Communication Systems
SATcom:

• (2) Thrane & Thrane Fleet 77

VSAT:

• (2) Sea Tel V-Sat broadband terminals 4006 and 4003 with VOIPs

Telephone System:

• Panasonic KX-TDKX1232

SSB Radio:

• Furuno FS-2575-C

VHF Radiotelephones:

• (2) Furuno FM-8900S
• (15) Icom portables

GPIRB:

• (2) Jotron 40S and ACR Global Fix Pro

AIS:

• (1) Furuno FA-170

Light Signal:

• (1) Astralux 0019

Cellular Phone System:

• Roaming GSM and V-Sat VOIP

Intercom:

• Door phone system
• Starlink Maritime with two antennas

Navigation Systems
Radar:

• (1) Furuno FR2105 X-Band
• (1) Furuno RCU-025 S-Band (Brand new)

Gyrocompass:

• Anschutz Standard 24 with TMC (twin)

Magnetic Compass:

• Cassens & Plath Delta-Pilot

Auto Pilot:

• Anschutz NP2010 type AP01-SO1

Depth Sounder:

• Furuno FCV-582L

Log:

• Ben Marine Anthea RGD100

GPS:

• (2) Northstar 952X

Ships Computer:

• (6) HP Laptops
• (3) Apple computers

Photocopier/Printer:

• (2) Officejet 7610
• (1) Canon MG5650

Chart Plotter:

• Transas

Wind/Speed Log:

• (2) B&G Hydra 2000

Navtex:

• (1) Furuno NX700

Loudhailer:

• Raytheon Ray 430

Air Horns:

• KahlenbergT-3 with M-511 whistle control

Entertainment System
a. Video Equipment

• Full Kaleidescape system / Full Apple-TV with iPad controls in all guest and crew areas with flat screens throughout
• Wireless network and hard-wired network

TVs: • Satellite television throughout the boat and in all cabins.

B. Audio Equipment
Stereos:

• State-of-the-art audio-visual systems throughout the boat and in all cabins.
• All new in refit 2015 at MB92

C. Wi-Fi Internet Access

• Both V-Sat and roaming 4G GSM

Main Galley Equipment
Cooking Equipment:

• (2) MKN Hans Dampf Pro Steamer ovens
• (1) Techoinox salamander
• (6) Miele cook plates CS1222
• (1) Panasonic NE 1456 stainless microwave

Refrigeration/Freezer:

• (3) Heinen Hopman stainless refrigerator
• (1) Heinen Hopman stainless walk-in freezer

Dishwasher:

• (2) Winterhalter UC

Other:

• (1) Dumbwaiter-Main deck pantry
• (1) Broan 8251T-03 trash compactor
• (1) Scotsman AC-45 icemaker

Crew Galley/Mess Equipment
Cooking Equipment:

• (1) Miele M8151-2 microwave

Refrigeration/Freezer:

• (1) Miele FD 9004 refrigerator

Other:

• (1) Broan 8251T-03 trash compactor

Additional Galley Equipment
Cooking Equipment:

• (1) Miele M8151-2 microwave (upper pantry)
• (1) Solaire infrared gas BBQ grill (sun deck)

Refrigeration/Freezer:

• (1) Miele FD 9004 refrigerator (main deck pantry)
• (1) Miele K 9552ID refrigerator (upper pantry)
• (1) Custom drawer refrigerator (sun deck)

Other:

• (1) Scotsman AC45 icemaker (main deck)
• (1) icemaker (upper deck pantry)
• (1) icemaker (sun deck)
• (1) Nespresso coffee machine (main deck pantry)
• (1) Dumbwaiter (upper deck pantry)
• (1) Carpigianni frozen yogurt machine (upper deck pantry) 

Laundry Equipment
Main Laundry Equipment

• (3) Miele Professional PW6065 Vario washers
• (3) Miele Professional PT7136 Vario dryers
• (1) Miele HN 5310 roller iron

Tenders:

• (1) 19’ Castoldi jet tender solas (new 2022)

Other:

• (2) SeaBob (new 2022)
• (2) Seadoo (new 2022)

Jacuzzi Dip Pools:

• (1) Scandi Aqualine on Owner’s deck
• (1) Scandi Aqualine on sun deck

BBQ:

• (1) Solaire infrared gas grill on sun deck

Anchor Windlass System:

• (2) Muir VR1500

Aft Warping Capstans:

• (2) Muir VR1200

Anchors:

• (2) Pool fully balanced 585 kg

Anchor Chain:

• (6) shots of U2 24 mm stud link each side

Boat Crane and Davits:

• (2) 2 meter Ascon/Van Driel

Passerelle:

• Cramm

Side Boarding Ladders:

• Cramm hydraulic starboard side
• 9-step Marquip Sea Stair

Searchlight:

• (1) Sanshin HRX-150

Awning:

• (2) Retractable on sun deck
• (1) Fixed over Owner’s private seating area forward
• (2) Windbreakers on Bridge deck aft

Gym Equipment:

• Nordic Track Elliptical
• (2) Lemond exercise bikes
• Nordic Track treadmill
• ProElixe vibration machine
• Free weights (up to 40kg)

Security Equipment
CCTV System:

• Elbex

Cameras:

• (7) security

Monitors:

• All around crew quarters

Ship’s Safe:

• (7) Total onboard.
• (1) Owner’s suite
• (1) Each of the five guest cabins
• (1) Captain’s cabin

Fire Fighting Equipment
Fire Control System:

• Heinen & Hopman sprinkler system

Fire Extinguishers:

• Fixed Co2 in Galley, ER and Jetski pods.
• (22) 2kg powder
• (2) 6kg powder
• (9) 9L foam
• (1) 20kg Co2
• (2)5kg Co2
• (2) 2 kg Co2
• (1) 9L Chemical foam

Alarms:

• Tyco Minerva fire addressable detection system
• MCS-5 alarm system
• Gas detection alarm for BBQ
• Gas detection for Jet ski pods

Safety Equipment

• Full complement of safety gear to more than comply with Flag, Lloyd’s and MCA rules

Life Rafts:

• (2) 25 persons and (1) 6-persons

Life Rings:

• (10) 2x light and smoke
• (1) self-igniting light
• (7) 30m line

EPIRBS:

• (2)

Flares:

• Smoke, rockets and flares

Medical Equipment:

• Ocean going full Category A

EEBDs:

• (30) Oceanco M-20.2 and Drager CF10

Sleeps up to 12 guests in the Owner’s party in 6 staterooms plus 7th stateroom on lower deck as gym / massage room, plus crew accommodations for up to 13 in 7 cabins

OWNER
The Master stateroom is on the main deck forward, full beam and is split level.
Entering through a large private office on the starboard side, up a short-fanned stairway to the Master bedroom, providing a 180-degree view of the outdoors. Down the stairs on the port side is the bathroom with Jacuzzi tub and then mid ship is the owner’s dressing, with access to both port and starboard. The Master Owner’s suite also has a private deck forward with seating and Jacuzzi.

GUESTS
(3) Double cabins on the lower deck, including 2 with bath en suite, 1 with shower ensuite.
(2) Twin cabins on the lower deck, including shower en suites.
(1) Large playroom / gym area. This stateroom has a large storage closet for guest luggage and additional stores.

GUEST AREAS
The Main Salon features comfortable seating with large floor to ceiling windows on either side.

Walk forward to the starboard side, where there is the guest lobby and staircase, separating the dining room.

To the port side, pantry area for service-through the dining room, and into the galley (access on both sides).

The Dining Room is separated from the main lounge and again, benefits from full floor to ceiling windows.

Forward is a day head and access to the Galley port side forward before a separate door with access to the Master Owner’s suite.

The Upper Deck is an active area for the guests, with vista views from the aft circular window, with a semi-circular sofa.

To the port side, there is a lovely bar with seating, and to starboard, a gaming table.

The Upper deck lounge leads out onto the aft deck veranda with al fresco dining.
Forward is access to the Captain’s cabin, office and bridge.

The Sun Deck has a lovely circular settee and veranda dining, sunbeds, wet bar and Jacuzzi pool surrounded by padded sun pads.

The tenders are stored on the main deck aft. The bridge has a comfortable central seating area for guests to view the yacht’s operations. There is also a large swim platform lower deck aft, with easy on-off tender boarding, and clever fast launch jet ski lateral lazarettes. (2) Jet skis (one port, one starboard).

CREW
(1) Captain’s cabin with a double bed and en-suite bathroom
(5) Double crew cabins with en-suite bathrooms
(1) Single cabin with en-suite bathroom and office

2023/2024

• Exterior Light Fittings: Replaced all 235mm exterior lights with LED fixtures
• Underwater Lights: Replaced 10 lights in the aft
• Main Hydraulic Tank: Drained, flushed, inspected, and filters replaced
• A/C Plant: Completed annual service
• AHUs (Fan Coils): Completed replacement of all units
• Galley Hood & Laundry: Cleaned laundry dryer air extraction fan & vent
• Laundry: Miele completed yearly service of washers and dryers
• Main Engines: Inspected for minor leaks; including overhaul of injectors on both engines
• Hull: Dry-docking with new antifouling and installed zincs
• Cathelco Anodes: Installed new anodes
• Hydraulic Overhaul: Overhauled hydraulic rams on jet ski doors
• Main Engine Exhaust Gaskets: Main exhaust pipes and gaskets replaced
• Main Engine Turbochargers: Turbo chargers inspected & new Gaskets installed
• Diesel Tanks: Cleaned and inspected by Lloyds
• Black & Grey Water Tanks: Cleaned and inspected by Lloyds
• Interior & Deck: Added new beach towels, two sets of cushion covers, and new iPads
• Sound System: Upgraded
• Teak/Caulking: Replaced all exterior teak steps including the swim platform
• Deck and Swim Platform Storage Compartments: resealed and replaced interior compartments and installed new seal on hatches
• Lazarette: Reorganized aft lazarette, removed toolbox, and making shells for batteries
• Bridge: Installed new PC with Navionics System

2022/2023

• Hull and superstructure polished and coasted, the original paint came back to 98% of the original paint
• Below waterline was brought back to bare metal and recoated and 2 coats of anti-fouling
• New Castaldi 19' SOLAS tender
• Teak deck repairs including replacement of teak in numerous areas
• Major Overhaul port & stbd generators
• Main engines fully serviced including new injectors
• Exhaust system upgraded
• Numerous technical improvements to systems, deck repairs and electrics
• Gangway and side boarding letter extensive repairs and upgrade (upon delivery last year did not operate properly)
• Surface Treatment and preservation - lockers, removal of rust and further touch up to various areas
• Improved audio-video AV/IT equipment
• New professional custom-built galley including 2 new ovens and all new cutlery
• New outside furniture cushions etc. including 4 Tucci umbrellas and custom built-in sofas on the sky-lounge deck.
• New bar area in sky-lounge with wine cooler, icemaker and fridge ample storage has been created.
• Upgraded Wi-Fi system
• 2 New Jacuzzis
• New Tecnogym equipment
• New carpet throughout
• New TV's Samsung throughout including 3 x 65'
• New mattrasses top of the line in all staterooms and crew quarters
• Dining Room furniture new throughout
• New sofas in main salon and sky-lounge
• New marble in bar area in sky-lounge
• All furniture in owner's stateroom replaced including study with new desk and chair
• New curtains throughout
• New Seabobs (two) and old 2 jet skis painted and serviced fitted with Bluetooth
• Fun-air floating swimming pool
• New outside covers throughout
• New glass ware, plates and crockery for owner/guests (OFE)
• New artwork (OFE)

2019

• Main Engines: W4, rebuilt the heat exchangers, rebuilt after coolers & borescope / NDT for class
• ZF: endoscopic examination A3 service
• Generators: W4, new heat exchangers, sea water pumps, thermostats, new vibration mounts, new AVR, borescope investigation for class
• Refrigeration Plant: new compressors, new evaporators, new control board and new refrigeration lines. Completely removed 20-year old system and updated to be 2020 compliant
• Under Water Lighting: New underwater lights LED upgrade
• Stabilizers: Major overhaul 8000 hrs service from Quantum.
• Watermakers: Completely rebuilt the entire system. New membranes on both units
• Fresh Water Plant: Overhaul of the entire system. New cold & hot distribution manifolds, both boilers complete overhauled, all hot water circulators replaced, (3) new GROHE water filtering system for drinking water (no plastic, environmentally friendly), (2) instant boilers in pantries, new Hydrophore pressure tank in stainless steel, fresh water tank painted and (3) new fresh water pumps
• Fire Sprinkler System: new distribution manifold with test valves, new pump and motor, and new control board on bridge
• Bilge & Fire Pumps: both rebuilt with new motors
• Tanks: All cleaned and inspected by Lloyds
• Deck Crane: 10-year service. Complete overhaul. New belts, breaks, falls etc.
• Electric: megger test of motors and heaters, discharge curve for each batteries group
• Wi-Fi: Antenna and 4g system upgraded to Poynting antennas with new Pep wave cellular routers (increased range & speed)
• Phone System: New phone system installed in all cabins, common areas and technical spaces
• Main Engine Start Batteries replaced
• Alfa Laval: major service
• Black Water Plant: Complete overhaul of entire plant. All pumps rebuilt
• Grey Water Plant: grey pipeline circuit cleaned
• 20 Year Lloyd Survey: Tail Shafts overhauled by manufacturer, Rubber Design. Hull thickness measurement, all through hull valves overhauled and tested, all bilge and fire manifold valves in Engine Room overhauled and tested. Noise and vibration test, main electric distribution board cleaned & insulation tested

2018

• Anchor: (2) NEW
• Main Engines: complete repainting
• Engine room: Deck plates powder coated
• Windlesses: both rebuilt
• Watermakers: HP pumps both rebuilt
• Tanks: cleaned and inspected
• E. Room Ventilation Fan: new installed
• Generator start batteries replaced

2016

• Main Engines: W6 major overhaul
• Generators: W6 major overhaul

2015

• 15-year Flag and Class survey
• Air Conditioning: New plant installed by Heinen & Hopman
• Painted hull
